Heavy duty multi-turn absolute encoder SAAM115

Product Features:

Heavy-duty construction designed for good impact resistance

Multi-angle wire outlet, convenient for customer installation and maintenance

Stainless steel shaft, waterproof sealing ring for increased protection level

Protection class IP66

European standard flange mounting and base mounting options are available.

Adjustable corresponding value per revolution, adjustable direction, adjustable preset position, adjustable external zero position

Product Description:

SAAM115Series Heavy DutyMulti-turn absolute encodersThe heavy-duty construction design provides excellent resistance to vibration and mechanical damage. It can withstand heavy axial and radial loads. SAAM115Series mechanical installation with flange mounting and base mounting two ways to choose from, multi-angle outlet direction can be selected, greatly facilitating customers to install according to the site conditions.

Electrical output interfaces are analog 4-20mA, 0-5V, 0-10, 0-20mA output and

Digital SSI, RS485, Modbus-RTU, CANopen, Profibus-DP, and Ethernet ProfiNet outputs for selection.

Maximum resolution8192Maximum number of laps4096The resolution and number of turns can be adjusted according to the needs. Its high speed communication and good anti-interference ability make the operation of customer's equipment more stable.
